HDL-80C Special for tunnel operation drill rig
HDL-80C Special for tunnel operation drill rig
| Applicable Industries: | Construction works , Energy & Mining | Showroom Location: | None |
| Condition: | New | Type: | Rotary Drilling Rig |
| Power Type: | Electric | Place of Origin: | Jiangsu, China |
| Brand Name: | ANMAN | Usage: | Water Well |
| Dimension(L*W*H): | 7550*1800*2700 | Weight: | 7200 KG |
| Warranty: | 1 Year | Marketing Type: | New Product 2022 |
| Machinery Test Report: | Provided | Video outgoing-inspection: | Provided |
| Warranty of core components: | 1 Year | Core Components: | Motor, Pump, Engine |
| Key Selling Points: | Top drifter drill | Drilling Diameter: | 50mm, 100mm |
| Drilling Depth: | Max.30m | Mobility: | available |
| Rated rotary speed(max)(r/min): | 144 | Rated output torque(max)(N.m): | 4400 |
| Rated lifting force (kN): | 45 | Rated feeding force (kN): | 27 |
| Supply Ability | 100 Set/Sets per Month |
| Packaging Details | Drilling rig naked, other accessories carton packaging | Port | Shanghai Port |
HDL-80C
HDL series drilling rig is top drive type multifunctional drilling rig which our company design and manufacture for complex formation according to market request.
|
Model number |
HDL-80C |
|
Hole diameter(mm) |
Φ50~Φ108 |
|
Hole depth(m) |
0~30 |
|
Rod diameter(mm) |
Φ50, Φ60, Φ73，Φ89 |
|
Hole angle(°) |
-45~105 |
|
Output speed of rotary head(max)(r/min) |
144 |
|
Output torque of rotary head(max)(N.m) |
4400 |
|
Lifting speed of rotary head(m/min) |
0~9,0~15 |
|
Feeding speed of rotary head(m/min) |
0~18,0~30 |
|
Input power(Electromotor)(kW) |
55 |
|
Dimension(L*W*H)(mm) |
7550*1800*2700 |
|
Vertical Working Dimension (L*W*H)(mm) |
7600*1800*4200 |
|
Weight(kg) |
7200 |
|
Impact power of rotary head（max）(N.m) |
320 |
|
Impact frequency of rotary head（max）(b/min) |
2500（max） |
|
Rated lifting force (kN) |
45 |
|
Rated feeding force (kN) |
27 |
|
Feeding stroke(mm) |
2300 |
|
Sliding stroke(mm) |
900 |
|
Climbing angle(°) |
20 |
|
Working pressure(MPa) |
20 |
|
Walking speed(m/h) |
1000 |
|
Gripper diameter(mm) |
Φ50～Φ89 |
|
Lifting height(mm) |
2165 |
|
Maximum construction height(mm) |
4690 |
Omnidirectional variable angle mechanism—more flexible, suit for many kinds of projects
Turn plate structure—more flexible for jet grouting hole construction
Clamp—reduce labor intense
Remote control——more safer.
